001 CYLINDER BLOCK

Таблица-описание

Key	Parts No	Description
1	65.01101-6079	CYLINDER BLOCK ASS`Y
1	65.01101-6079A	CYLINDER BLOCK ASS`Y
1	65.01101-6079B	CYLINDER BLOCK ASS`Y
1	65.01101-6079C	CYLINDER BLOCK ASS`Y
1	65.01101-6079D	CYLINDER BLOCK ASS`Y
1A	65.01101-0030F	. BLOCK;CYLINDER
1A	65.01101-0030G	. BLOCK;CYLINDER
1A	65.01101-0030H	. BLOCK;CYLINDER
1A	65.01101-0030I	. BLOCK;CYLINDER
1B	65.01105-1048	. CAP;BEARING(F.M.R)
1B	65.01105-1048A	. CAP;BEARING
1C	65.01105-1047	. CAP;BEARING(NO.4)
1C	65.01105-1047A	. CAP;BEARING
1D	65.91710-0001	. RING;STOPPER
1E	65.90020-0066A	. BOLT;BRG CAP
1F	65.04410-0007A	. BUSH;CAM SHAFT
1F	65.04410-0007B	. BUSH;CAM SHAFT
1F	65.04410-0007C	. BUSH;CAM SHAFT
1F	65.04410-0007D	. BUSH;CAM SHAFT
1G	65.04410-0006A	. BUSH;CAM SHAFT
1G	65.04410-0006B	. BUSH;CAM SHAFT
1G	65.04410-0006C	. BUSH;CAM SHAFT
1H	65.90302-0009	. PLUG;CORE
1I	06.15091-0319	. PLUG;CORE
1I	65.90302-0041	. PLUG;CORE
1J	06.15091-0322	. PLUG;CORE
1J	65.90302-0042	. PLUG;CORE
10	65.01201-0067	LINER;CYLINDER (ALTV.)
10	65.01201-0068	LINER;CYLINDER(1A)
10	65.01201-0069	LINER;CYLINDER(1B)
10	65.01201-0070	LINER;CYLINDER(2A)
10	65.01201-0071	LINER;CYLINDER(2B)
11	65.01110-6090B	METAL;CRANK STD
11	65.01110-6091B	METAL;CRANK 0.25
11	65.01110-6092B	METAL;CRANK 0.50
12	65.01150-6010A	WASHER;THRUST STD
12	65.01150-6008	WASHER;THRUST
12	65.01150-6034A	WASHER;THRUST 0.25
12	65.01150-6035A	WASHER;THRUST 0.50
13	65.01601-5010A	OIL JET PIPE
14	65.05401-5023	RELIEF VALVE ASS`Y
15	06.15091-0313	PLUG;CORE
16	65.90201-0058	BOLT;STUD M14X1.5X45
17	65.01112-0021A	COVER;PUSH ROD CHAMBER
18	65.01112-5018	COVER;PUSH ROD CHAMBER
18	110508-00358	COVER;PUSH ROD CHAMBER
19	65.01901-0020	GASKET
20	65.96507-0007	PACKING
21	65.90020-0049	BOLT;HEX.
22	65.91615-0011	COVER;BLIND
23	65.05903A0013	GASKET
24	06.01913-3113	BOLT
25	65.90320-0022	PLUG SCREW
26	65.91605-0001E	COVER
27	06.56021-0106	O-RING
28	06.01913-3113	BOLT
29	65.90310-0135	PLUG;SCREW
30	06.56190-0706	SEAL RING
40	65.05401-5002F	RELIEF VALVE ASS`Y
40	65.05401-5002G	RELIEF VALVE
41	06.56021-0102	O-RING
42	65.90310-0030	SCREW;PLUG
43	06.56190-0704	RING;SEAL
44	65.27441-7006	SWITCH;OIL PRESS
45	65.90201-0182	BOLT;STUD
46	65.90320-0019	PLUG SCREW
50	65.98130-0040A	ADAPTER
51	65.06310-6003	PLUG;DRAIN
51	65.06310-6003A	PLUG;DRAIN
51	65.90310-0122	PLUG;DRAIN
52	04.50010-0811	HOSE;VINYL
53	06.56190-0713	RING;SEAL
54	65.97401-0050	CLIP;PIPE

001 CYLINDER BLOCK
