001 CYLINDER BLOCK

Таблица-описание

Key	Parts No	Description	Qty
1	65.01101-6079D	CYLINDER BLOCK ASS`Y	1
1	150102-00483A	CYLINDER BLOCK ASS`Y	1
1	150102-00483B	BLOCK ASSY,CYLINDER	1
1	150102-00483C	BLOCK ASSY,CYLINDER	1
2	65.01101-0030I	BLOCK;CYLINDER	1
3	65.01105-1048A	CAP;BEARING	6
3	140202-00384	CAP,BEARING	6
5	65.01105-1047A	CAP;BEARING	1
5	140202-00016A	CAP ASSY,BEARING;THRUST	1
7	65.91710-0001	RING;STOPPER	2
8	65.90020-0066A	BOLT;BRG CAP	14
8	120112-01340	BOLT	14
9	65.04410-0007C	BUSH;CAM SHAFT	1
9	65.04410-0007D	BUSH;CAM SHAFT	1
9	130702-00304	BUSHING;CAMSHAFT	1
10	65.04410-0006C	BUSH;CAM SHAFT	5
10	130702-00303	BUSHING;CAMSHAFT	5
11	65.90302-0009	PLUG;CORE	2
12	65.90302-0041	PLUG;CORE	2
13	65.90302-0042	PLUG;CORE	3
15	65.90310-0030	SCREW;PLUG	1
16	06.56190-0704	RING;SEAL	1
17	65.90320-0019	PLUG SCREW	1
18	06.15091-0313	PLUG;CORE	2
19	65.90320-0022	PLUG SCREW	10
20	65.90201-0058	BOLT;STUD M14X1.5X45	1
20	65.90201-0063	BOLT;STUD	1
21	65.91605-0001E	COVER	1
22	06.01913-3113	BOLT	2
23	65.01112-0021A	COVER;PUSH ROD CHAMBER	2
24	65.01112-5018	COVER;PUSH ROD CHAMBER	1
25	65.90020-0049	BOLT;HEX.	6
26	65.96507-0007	PACKING	6
27	65.01110-6090B	METAL;CRANK STD	7
27	140103-00173	BEARING,MAIN;UPR, STD	7
27	140103-00174	BEARING,MAIN; LWR,STD	7
27	65.01110-6091B	METAL;CRANK 0.25	7
27	65.01110-6092B	METAL;CRANK 0.50	7
28	65.01150-6008	WASHER;THRUST	2
28	65.01150-6034A	WASHER;THRUST 0.25	2
28	65.01150-6035A	WASHER;THRUST 0.50	2
29	65.91615-0011	COVER;BLIND	1
30	06.01913-3113	BOLT	2
31	65.01201-0067	LINER;CYLINDER (ALTV.)	6
31	65.01201-0068	LINER;CYLINDER(1A)	6
31	65.01201-0069	LINER;CYLINDER(1B)	6
31	65.01201-0070	LINER;CYLINDER(2A)	6
31	65.01201-0071	LINER;CYLINDER(2B)	6
36	65.01901-0020	GASKET	3
37	06.56021-0106	O-RING	1
38	65.90310-0135	PLUG;SCREW	1
39	06.56190-0706	SEAL RING	1
40	65.05903A0013	GASKET	1
42	65.90310-0122	PLUG;DRAIN	1
45	06.56190-0713	RING;SEAL	2
46	65.01601-5010A	OIL JET PIPE	6
47	65.05401-5023	RELIEF VALVE ASS`Y	6
48	06.56021-0102	O-RING	1
52	65.05401-5002F	RELIEF VALVE ASS`Y	1
52	65.05401-5002G	RELIEF VALVE	1
53	65.27441-7006	SWITCH;OIL PRESS	1
54	65.90201-0182	BOLT;STUD	1
