005 CYLINDER HEAD

Таблица-описание

Key	Parts No	Description
101	65.03101-6071B	CYLINDER HEAD ASS`Y
101	65.03101-6071C	CYLINDER HEAD ASS`Y
101	150113-00048	HEAD ASSY,CYLINDER
101	150113-00048A	HEAD ASSY,CYLINDER
102	-	HEAD;CYLINDER
102	-	HEAD;CYLINDER
102	-	HEAD,CYLINDER
104	65.03201-1013A	GUIDE;VALVE
105	65.03203-1054	SEAT;EXHAUST VALVE
106	65.03203-1053	SEAT;INLET VALVE
107	65.90302-0015	PLUG;CORE(NEAR FACE)
108	65.90302-0030	PLUG;CORE(EXHAUST MAIN)
109	65.90302-0019B	PLUG;CORE
110	65.90302-0045	PLUG;CORE
111	65.90302-0027	PLUG;CORE
112	65.90302-0011	PLUG;DRILLED PASS
113	65.90302-0017	PLUG;WATER JET CORE
116	06.06225-0706	BOLT;STUD
117	06.06125-8717	BOLT;STUD
118	06.06125-8709	BOLT
119	65.91710-0004	RING;STOPPER
120	65.90021-0002	BOLT;CYLINDER HEAD
121	65.90021-0003	BOLT;CYLINDER HEAD
122	65.90021-0004	BOLT;CYLINDER HEAD
123	06.06125-8723	BOLT;STUD
124	65.19202-5005	HOOK;LIFTING
125	65.03901-0066A	GASKET;CYLINDER HEAD
125	400603-00071	GASKET,CYLINDER HEAD
128	06.16731-2110	WASHER;SPRING
129	06.01733-4409	BOLT;HEX
130	06.16731-2108	WASHER;SPRING
131	06.01733-4208	BOLT
132	65.26815-0002	PLUG;DUMMY
132	65.26815-0004	PLUG
133	65.19202-0005	HOOK;LIFTING
134	06.01943-3213	BOLT
200	65.03401-6097B	CYLINDER HEAD COVER ASS`Y
200	150106-00006	CYLINDER HEAD COVER ASS`Y
201	65.03401-6094	COVER;CYL. HEAD
201	65.03401-6094A	COVER;CYL. HEAD
202	06.04190-8808	BOLT
203	06.16731-2104	WASHER;SPRING
204	06.15010-0308	WASHER;PLAIN
205	65.03903-0001	PACKING;BREATHER PIPE
206	65.01801-0011	CASE;BREATHER
207	65.03905-0002C	GASKET;CYLINDER HEAD COVER
207	400603-00022	GASKET;CYLINDER HEAD COVER
209	65.90501-0028	NUT;CYLINDER HEAD COVER
210	65.90701-0202	WASHER;PLATE
211	65.03905-0023A	GASKET;CYLINDER HEAD COVER
220	65.01810-5011	CAP,OIL FILLER
223	65.01801-5035A	BREATHER PIPE ASS`Y
224	65.96501-0032B	O-RING;BREATHER
