015 FUEL SYSTEM

Таблица-описание

Key	Parts No	Description
1	65.10101-7090	NOZZLE HOLDER ASS`Y
1	65.10101-7092	NOZZLE HOLDER ASS`Y
1	65.10101-7099	NOZZLE HOLDER ASS`Y
1	65.10101-7099A	NOZZLE HOLDER ASS`Y
1	65.10101-7085A	NOZZLE HOLDER ASS`Y
1	65.10101-7085B	HOLDER ASSY,NOZZLE
1A	65.10102-6060	. NOZZLE
1A	65.10102-6064	. NOZZLE
1A	65.10102-6069	. NOZZLE
1A	65.10102-6055	. NOZZLE
1A	65.10102-6055A	. NOZZLE
2	65.96507-0050	SEAL;RING
3	65.96507-0044A	RING;SEAL
3	65.96507-0044B	RING;SEAL
4	65.90201-0099	BOLT;STUD
5	06.11063-8214	NUT
6	06.16731-2107	WASHER
10	65.10301-6085	PRESSURE PIPE ASS`Y
10	65.10301-6088	PRESSURE PIPE ASS`Y
10	65.10301-6202	PRESSURE PIPE ASS`Y
11	65.10301-6086	PRESSURE PIPE ASS`Y
11	65.10301-6089	PRESSURE PIPE ASS`Y
11	65.10301-6203	PRESSURE PIPE ASS`Y
12	06.16731-2107	WASHER
13	06.15010-2311	WASHER
14	06.11063-8214	NUT
20	65.11101-7384	PUMP;INJECTION
20	65.11101-7391	PUMP;INJECTION
20	400912-00070	PUMP ASSY,INJECTION
20A	105220-649A	. PUMP,FEED
20AA	400908-00004	.. HAND PRIMING PUMP
20B	131150-2620	. PLUNGER
20C	131110-5520	. VALVE;DELIVERY
20D	131424-1520	. VALVE;OVERFLOW
20E	156639-8820	. COUPLING
21	65.11902A0001	GASKET;INJECTION PUMP
22	65.05701-5200	PIPE;OIL
22	65.05701-5328	PIPE;OIL
23	65.98155-0011	UNION;HOLLOW
24	06.12172-9314	NUT;CAP
25	65.08301-6010A	HOSE;AIR
26	65.98150-0053B	SCREW
27	06.56180-0714	RING;SEAL
28	06.56180-0714	RING;SEAL
29	65.97403-0014	BRACKET
30	06.01943-3213	BOLT
31	06.01923-3112	BOLT
32	65.11401-0002C	BRACKET;REAR
33	06.01913-3122	BOLT
34	06.01913-3124	BOLT
35	06.01283-7128	BOLT;HEX
36	06.16731-2107	WASHER
37	06.01953-3213	BOLT
38	06.15010-2312	WASHER;PLAIN
39	06.11063-9215	NUT
40	06.16731-2108	WASHER;SPRING
41	65.11596-0001	WIRE;SEAL
42	65.11596-0002	WIRE;SEAL
50	65.96341-0107	HOSE;FUEL
50	65.96341-0100	HOSE;FUEL
50	65.96341-0140	HOSE,FUEL
51	06.78144-2204	SCREW;HOLLOW
52	65.96507-0043	RING;SEAL
53	06.78144-2204	SCREW;HOLLOW
54	65.96507-0043	RING;SEAL
55	65.12301-5824	PIPE;FUEL
56	06.56180-0712	RING;SEAL
56	65.96501-0001	RING;SEAL A8X14
57	65.96301-0176	HOSE;RUBBER
58	65.97401-0089	CLIP
59	65.12301-5825	PIPE;FUEL(RETURN)
60	65.12301-5022	PIPE;FUEL(RETURN)
61	65.98150-0015B	SCREW;HOLLOW
62	65.97460-0002	CABLE TIE
63	65.96341-0080	HOSE;FUEL
63	65.96341-0100	HOSE;FUEL

015 FUEL SYSTEM
