016 FUEL SYSTEM

Таблица-описание

Key	Parts No	Description
101	65.10101-7099A	NOZZLE HOLDER ASS`Y
101	65.10101-7085B	HOLDER ASSY,NOZZLE
101	150118-00135	HOLDER ASSY,NOZZLE
101	150118-00113	NOZZLE ASSY,INJECTION
102	65.10102-6069	NOZZLE
102	65.10102-6055	NOZZLE
102	65.10102-6055A	NOZZLE
102	150118-00122	NOZZLE,FUEL INJECTION
104	65.96507-0044B	RING;SEAL
106	65.96507-0050	SEAL;RING
108	65.90201-0099	BOLT;STUD
109	06.11063-8214	NUT
110	06.16731-2107	WASHER
201	65.10301-6088	PRESSURE PIPE ASS`Y
201	65.10301-6202	PRESSURE PIPE ASS`Y
202	65.10301-6089	PRESSURE PIPE ASS`Y
202	65.10301-6203	PRESSURE PIPE ASS`Y
301	65.11101-7420A	PUMP;INJECTION
301	400912-00071	PUMP ASSY,INJECTION
304	06.67020-0101	CLAMP;HOSE
305	65.08301-6008	HOSE;AIR
306	65.98131-0050	CONN SCREW
307	06.56180-0714	RING;SEAL
308	65.05701-5200	PIPE;OIL
309	65.98155-0011	UNION;HOLLOW
310	06.12172-9314	NUT;CAP
311	06.56180-0714	RING;SEAL
320	65.11596-0001	WIRE;SEAL
321	65.11596-0002	WIRE;SEAL
330	150112-00007	GOVERNOR KIT
401	06.01913-3122	BOLT
402	06.01913-3124	BOLT
404	06.01283-7128	BOLT;HEX
405	06.16731-2107	WASHER
406	65.11401-0002C	BRACKET;REAR
407	06.01953-3213	BOLT
408	06.15010-2312	WASHER;PLAIN
409	06.11063-9215	NUT
410	06.16731-2108	WASHER;SPRING
411	65.11902A0001	GASKET;INJECTION PUMP
501	65.12301-5022	PIPE;FUEL(RETURN)
502	65.96341-0100	HOSE;FUEL
502	65.96341-0140	HOSE,FUEL
503	06.78144-2204	SCREW;HOLLOW
504	65.96507-0043	RING;SEAL
505	06.78144-2204	SCREW;HOLLOW
506	65.96507-0043	RING;SEAL
507	65.12301-5824	PIPE;FUEL
508	65.98150-0015B	SCREW;HOLLOW
509	06.56180-0712	RING;SEAL
509	65.96507-0001	RING;SEAL
510	65.12301-5825	PIPE;FUEL(RETURN)
511	65.96301-0176	HOSE;RUBBER
512	65.97401-0089	CLIP
513	65.97460-0002	CABLE TIE
515	65.96341-0100	HOSE;FUEL
515	65.96341-0140	HOSE,FUEL

016 FUEL SYSTEM
