1740 ELECTRIC PARTS

Таблица-описание

Key	Parts No	Description
-	300619-09308K	ELECTRIC ASSY,CABIN
-	300619-09308L	ELECTRIC ASSY,CABIN
-	300619-09308M	ELECTRIC ASSY,CABIN
-	300619-09308P	ELECTRIC ASSY,CABIN
4	S3450983	SCREW
5	S5102303	WASHER,SPRING
6	S3450833	SCREW
7	S5100203	WASHER
8	543-00095	PANEL ASS`Y
13	549-00103	SWITCH
14	K1056625	ACTUATOR,HEADLIGHT
15	301401-00008	ACTUATOR,SWITCH(HIGH SPEED)
19	310207-00708C	HARNESS,JOINT
20	S5100003	WASHER
21	S3450343	SCREW
22	300712-00089	BUZZER,24V
23	S3450943	SCREW
24	124-00208D3	CLIP
25	120106-00596	BOLT
26	S3450953	SCREW
27	S5102503	WASHER
28	S0508653	BOLT M8X1.25X16
29	547-00023	SENSOR
30	120106-00702	BOLT
31	124-00208D5	CLIP
32	2121-1305	NUT
36	120402-00439	CLIP
38	310207-10641C	HARNESS,CABIN
38	310207-10641E	HARNESS,CABIN
38-1	300803-00524	. FUSE,BLADE;5A
38-2	2527-1016	. FUSE,BLADE 10A
38-3	2527-1017	. FUSE,BLADE 15A
38-4	2527-1018	. FUSE,BLADE 20A
38-5	2527-1025	. FUSE,BLADE 30A
38-6	2548-1027	. DIODE,2 PIN
38-7	300645-00247	. RESISTOR;1/2W - 120Ω
40	301401-00031	ACTUATOR,SWITCH(POWER)
41	K1056448	SWITCH,DETENT SET
42	301401-00030	ACTUATOR,SWITCH(WORK)
44	800224-00011	METER,HOUR
44	800224-00011A	METER,HOUR
45	DS0025056	BOLT
47	2120-2166D5	BOLT
48	2114-1898D2	WASHER
49	430224-00397	SOCKET ASSY;POWER, 24V
49	430224-00506	SOCKET;24V POWER
50	110433-00615	BRACKET,CONNECTOR
51	110406-08515	BRACKET;EPOS;LH
52	110406-08514	BRACKET;EPOS;RH
53	S5010513	WASHER,PLAIN
54	S0509266	BOLT
55	301421-00067	SWITCH,TOGGLE
56	950209-05155	PLATE,NAME
58	S5000213	WASHER
59	K1053326	RELAY
59	301202-00805	RELAY
60	549-00090A	SWITCH,TOGGLE
61	K1004427	PLATE,NAME
62	K1004426	PLATE,NAME
63	250201-06492	PLATE;2ND ENGINE SWITCH
64	2120-2166D52	BOLT
65	K1004425	PLATE,NAME
81	301405-00363	SWITCH,TOGGLE
91	300611-00944	CONTROLLER,ENGINE THROTTLE
92	S4012333	NUT
93	S5102303	WASHER,SPRING
94	S5010313	WASHER,PLAIN
101	K1026510	CAP
151	300611-01927	CONTROLLER,EPOS
151	300611-02388	CONTROLLER,EPOS
151	300611-02388A	CONTROLLER,EPOS;TIER2
151-1	970306-00373	. EPOS SOFTWARE
151-1	970306-00373A	. EPOS SOFTWARE(TIER2)
201	300426-00373A	PANEL ASSY,GAUGE;8 inch
201	300426-00373B	PANEL ASSY,GAUGE;8 INCH
201-1	970304-00057	. GAUGE SOFTWARE

1740 ELECTRIC PARTS - CABIN
