4150 TRAVEL MOTOR

Таблица-описание

Key	Parts No	Description
C	K9007410	CONTROL PART ASS`Y
C	300609-00069	CONTROL PART ASSY
C-1	K9007408	. FLANGE ASSY;REAR
C-1	K9007408A	. FLANGE ASSY;REAR
C-1	430215-00552	. FLANGE ASS`Y;REAR
C-2	K9007409	. FLANGE KIT;REAR
C-2	K9007409A	. FLANGE KIT;REAR
C-3	110956-00060	. STOPPER
1	-	REAR FLANGE
23	K9007399	MAIN SPOOL
23	410207-00163	SPOOL,MAIN
23	410207-00163A	SPOOL,MAIN
23	410207-00307	SPOOL,MAIN
24	1.181-00059	PLUG;FOR MAIN
25	110956-00071	STOPPER
26	1.181-00067	PLUG;CHECK
27	1.420-00013	VALVE;CHECK
28	1.131-00058	SPRING;FOR MAIN
30	1.129-00006	SPRING;CHECK
36	S8000321	O-RING
37	S8002731	O-RING
41	S5700891	PIN;PARALLEL
43	S2221471	BOLT,SOCKET
46	S8000181	O-RING
52	2181-1890D2	PLUG
52	2181-1890D2	PLUG
54	181-00318	PLUG
55	2181-1116D2	PLUG
63	2181-1890D4	PLUG
65	1.424-00041	SPOOL;2 SPEED
66	1.131-00001	SPRING
66	111601-00354	SPRING
68	S6250182	BALL
71	1.415-00005	ORIFICE
74	S8000111	O-RING
74	S8000111	O-RING
79	1.471-00001	FILTER
79	1.471-00001A	FILTER
91	2181-1116D1	PLUG
200	K9007407	CYL BLOCK & PISTON KIT
200	400701-00004	CYL BLOCK & PISTON KIT
205	K9007406	PISTON ASS`Y
205	K9007406A	PISTON ASSY
204	K9007397	BLOCK;CYLINDER
207	K9004447	PLATE;RETAINER
208	K9004448	BALL;THRUST
202	K9007415	SHAFT;DRIVE
202	K9007415A	SHAFT,DRIVE
203	K9007382	PLATE;SWASH
209	K9007398	PLATE;TIMING
209	K9007398A	PLATE,TIMING
212	K9004453	PISTON;PARKING
213	1.131-00049	SPRING
213	1.131-00049A	SPRING
214	K9004449	SPRING
215	412-00013	PLATE,FRICTION
216	352-00014	PLATE,SEPARATION
232	K9007401	SEAL;OIL
235	S8001801	O-RING
239	S8002101	O-RING
242	1.123-00053	PIN,PARALLEL
247	S8061800	RING;BACK UP
248	S8062100	RING;BACK UP
249	K9007400	BEARING;BALL
250	1.109-00026	BEARING;BALL
260	1.409-00180	PISTON KIT;2 SPEED
260	130602-00200	PISTON KIT;2 SPEED
261	1.131-00042	SPRING
261	111601-00117	SPRING,SPEED-ADJUSTING
267	1.540-00006	PIVOT
275	S8000081	O-RING
400	K9007413	RELIEF VALVE ASS`Y
400	410127-00058	VALVE ASSY,RELIEF
400	410127-00058A	VALVE ASSY,RELIEF
400	410127-00190	VALVE ASSY,RELIEF
401	-	PLUNGER
402	1.180-00527	SEAL;PISTON
403	-	BODY
404	S8060161	RING;BACK-UP
405	S8000161	O-RING
406	S8010291	O-RING
407	-	RETAINER;SPRING
408	-	SPRING
409	-	PISTON
410	S8000221	O-RING
411	S8060221	RING;BACK UP
412	-	PLUG,ADJUST
413	-	NUT,LOCK
*	K9008310	SEAL KIT;TRAVEL DEVICE

4150 TRAVEL MOTOR
