4151 TRAVEL MOTOR [1115~]

Таблица-описание

Key	Parts No	Description
-	401-00454	TRAVEL DEVICE
-	401-00454A	TRAVEL DEVICE
-	401-00454B	TRAVEL DEVICE
-	401-00454C	TRAVEL DEVICE
RL	1.215-00001	REAR FLANGE ASS`Y
RL	K9001812	REAR FLANGE ASS`Y
RL1	1.215-00002	KIT;REAR FLANGE
RL1	K9001813	KIT;REAR FLANGE
201	1.215-00003	FLANGE;REAR
201	-	FLANGE;REAR
223	1.424-00062	SPOOL;MAIN
RL2	1.416-00026	STOPPER ASS`Y
294	1.416-00027	STOPPER
295	1.424-00063	SPOOL;MAIN
296	1.129-00018	SPRING
297	1.114-00542	WASHER
298	S6550100	RING;SNAP
224	1.181-00059	PLUG;FOR MAIN
228	1.131-00058	SPRING;FOR MAIN
279	S8000321	O-RING
226	1.181-00067	PLUG;CHECK
227	1.420-00013	VALVE;CHECK
230	1.129-00006	SPRING;CHECK
234	S8002731	O-RING
221	2181-1890D4	PLUG
238	S8000181	O-RING
252	2181-1116D2	PLUG
244	2181-1116D1	PLUG
268	S6250161	BALL;STEEL
242	1.420-00014	VALVE;REDUCING
272	1.427-00031	SEAT;VALVE REDUCING
276	1.115-00141	RING;REDUCING
275	1.131-00062	SPRING;REDUCING V/V
218	1.427-00029	VALVE;SEAT T-TYPE
219	1.420-00009	VALVE;T-TYPE
220	1.131-00041	SPRING;T-TYPE
222	1.115-00139	RING;T-TYPE
233	S8000091	O-RING
263	422-00031	VALVE;TWO SPEED
264	116-00016	STOPPER;T/SPEED
264	K9001047	PLUG
265	411-00005	RING;TWO SPEED
265	S8000111	O-RING
266	1.131-00099	SPRING;TWO SPEED
241	S5700891	PIN;PARALLEL
282	S2221471	BOLT,SOCKET
297	1.415-00005	ORIFICE
M	1.401-00011	MOTOR PART
M1	1.441-00291	KIT;CYL`D BLOCK & PISTON
104	1.441-00292	BLOCK;CYL`D
110	1.114-00305	WASHER
114	1.129-00019	SPRING;FOR CYL`D
145	S6510700	RING;SNAP
M11	1.409-00231	PISTON ASS`Y
105	1.409-00232	PISTON
106	1.355-00011	SHOE
151	1.109-00135	ROLLER
107	1.412-00093	PLATE;RETAINER
108	1.148-00016	BALL;THRUST
M2	1.452-00004	PISTON ASS`Y
M2	K9001814	PISTON ASS`Y
161	1.409-00116	PISTON
162	1.355-00012	SHOE
163	1.131-00042	SPRING
102	1.405-00022	SHAFT;MAIN
103	1.412-00202	PLATE;SWASH
109	1.412-00203	PLATE;TIMING
115	1.412-00061	PLATE;FRICTION
116	1.412-00072	PLATE;MATING
112	1.409-00115	PISTON;PARKING
113	1.131-00055	SPRING;P/PISTON
132	1.180-00631	SEAL;OIL
149	1.109-00147	BEARING;BALL
150	1.109-00026	BEARING;BALL
139	S8002101	O-RING
178	S8011951	O-RING
180	S8000201	O-RING
181	S5701242	PIN
167	1.540-00006	PIVOT
R	1.441-00293	KIT;RELIEF V/V BLOCK
300	1.441-00294	BLOCK;VALVE
R1	1.426-00024	RELIEF VALVE ASS`Y
301	1.429-00037	SEAT
302	1.424-00064	PLUNGER
303	1.424-00065	ROD
304	1.409-00233	PISTON
305	1.441-00295	BODY
306	1.181-00154	PLUG
307	1.129-00020	SPRING
308	1.114-00543	SHIM
309	S8000181	O-RING
310	S8000181	O-RING
311	S8060181	RING,BACKUP
312	S2209661	BOLT;SOCKET M8X1.5X50
313	S5110501	WASHER;SPRING M8
900	2401-9082K	SEAL KIT
