1630 BATTERY COVER

Таблица-описание

Key	Parts No	Description
-	K1046071C	COVER ASS`Y
-	110508-00244	COVER ASSY
4	K1039067B	BATTERY COVER ASS`Y
4	K1039067C	BATTERY COVER ASS`Y
4	110503-00016A	COVER ASSY,BATTERY
4	110503-00016B	COVER ASSY,BATTERY
4	110503-00016C	COVER ASSY,BATTERY
4	110503-00016E	COVER ASSY,BATTERY
4	110503-00016G	COVER,BATTERY
4	110503-00016K	COVER,BATTERY
4	110503-00016L	COVER,BATTERY
4-1	-	. BATTERY COVER
4-2	K1038697A	. COVER
4-2	K1038697B	. COVER
4-2	110503-00008A	. COVER,BATTERY
4-2A	125-00071B	.. LATCH,FRONT
4-3	S0512066	. BOLT,HEX;M10X1.5X25
4-4	S5010613	. WASHER
4-4	120804-00076	. WASHER,HARD;M10
4-5	-	. RUBBER
4-6	-	. RUBBER
4-7	K1001968	. CYLINDER;GAS
4-7	400315-00026	. CYLINDER,GAS
4-8	S5102503	. WASHER
4-9	S4012533	. NUT
4-10	K1005305A	. STOPPER;RUBBER
4-10	110956-00362	. STOPPER,RUBBER
4-11	DS1001061	. CYLINDER;GAS
4-12	S4012333	. NUT
4-13	S5102303	. WASHER,SPRING
4-14	110406-01255	. BRACKET,CATCH
4-15	DS0025015	. BOLT,SET
11	621-03657B	COVER;TANK
11	110508-37369	COVER,TANK
15	K1013266B	STAY
25	DS0025014	BOLT
25	S0511866	BOLT,HEX;M10X1.5X20
26	DS0025015	BOLT,SET
26	S0515066	BOLT,M12X1.75X25
26	S0515066	BOLT,M12X1.75X25
27	195-02706C	BRACKET
27	110406-05389	BRACKET
31	S0560666	BOLT
32	S5102703	WASHER,SPRING;M12
32	S5102703	WASHER,SPRING;M12
33	S0560566	BOLT M12X1.75X40
33	S0560466	BOLT,HEX;M12X1.75X35
37	2114-1154	WASHER
39	S0515266	BOLT;M12X1.75X30
41	195-02624C	BRACKET
42	DS0025027	BOLT
42	DS0025025	BOLT,SET;M12X1.75X30
43	S5010713	WASHER
43	120804-00077	WASHER,HARD;M12
44	K1004630	CYLINDER,KEY
49	S0515166	BOLT M12X1.75X28
58	DS0401164	WASHER
59	S0514666	BOLT M12X1.75X16
60	120804-00078	WASHER,HARD;M10
61	120804-00079	WASHER
61	120804-00079	WASHER
101	K1040606	MIRROR,SIDE
102	K1038110A	STAY,MIRROR
103	S0561066	BOLT M12X1.75X65
104	2114-1058D68	WASHER
105	S4012733	NUT,HEX M12X1.75
106	161-00580	CAP,RUBBER
107	120804-00079	WASHER
131	S0561066	BOLT M12X1.75X65
132	2114-1058D68	WASHER
133	K1038107A	STAY,MIRROR
134	120804-00079	WASHER
135	S4012733	NUT,HEX M12X1.75
136	161-00580	CAP,RUBBER
137	K1040606	MIRROR,SIDE

1630 BATTERY COVER
